Spesifikasjoner:

Line inputs & outputs; XLR (balanced) & TS Jack (unbalanced)

Maximum output gain

30 dBu

Output impedance

75 O

Frequency range (Clean Gain 30 dB, Tube Gain off)

1 Hz – 310 kHz

Noise (A-weighted, Clean Gain 60 dB, Tube Gain off)

-67.2 dBu

THD + N (Clean Gain 24d B, Tube Gain off, Output +6 dB, 20 Hz -22 kHz)

0.0005 %

Common mode rejection (Clean Gain 30 dB, Tube Gain off, 1 kHz, Input -30 dBu)

> 80 dB

Dynamic range

130 dB

Microphone Preamplifier, XLR (balanced)

Maximum input gain (Mic)

17 dBu

Input impedance (switchable)

200 O, 1.2 kO, 10 kO

THD + N (Clean Gain 23 dB, Tube Gain 1 dB, Output +6 dB, 20 Hz -22 kHz)

0.032 %

Noise (A-weighted, Clean Gain 20 dB, Tube Gain 10 dB)

-86.4 dBu

Frequency range (Clean Gain 30 dB, Tube Gain 1 dB)

1 Hz – 125 kHz

E.I.N.

-127.2 dBu

Instrumenten Preamplifier, TS Jack (unbalanced)

Maximum input gain (Instrument)

17 dBu

Input impedance (Instrument)

1 MO

Internal Linear Power Supply with Shielded Toroidal Transformer

Operating voltage for analog audio

+/- 30 V

Operating voltage for relays and LEDs

+ 12 V

Mains Power Supply

Mains voltage (selectable)

230 V AC / 50; 115 V AC / 60 Hz

Fuse for 230 V

T 315 mA

Fuse for 115 V

T 630 mA

Power consumption

max. 25 W

Dimensions & Weight

W x H x D (width x height incl. feet x depth)

106 x 122 x 271 mm

4.17 x 4.8 x 10.67 inch

Unit weight

2.65 kg

5.84 lbs

Shipping weight (incl. packaging)

3.8 kg

8.38 lbs
